| Quantity: | |
|---|---|
| Product lype | Directional valve |
| Model Number | DCV100 Manual |
| Rated pressure | 350bar |
| Rated flow | 20-200L/min |
| Operating range | 15-75mm2/s |
| Working temperature | -40 to 80℃ |
| Min viscosity | 12mm2/s |
| Max viscosity | 400mm2/s |
| Monoblock | 1-8 sections |
| Control type | manual, joystick, cable, pneumatic, electro-hydraulic, etc. |
Tired of hydraulic valves that can't handle extreme pressure or fail under continuous operation? Meet the DCV100 Manual Spool Valve, the ultimate solution for demanding applications in construction machinery, agricultural equipment, and more. With an exceptional rated pressure of 350 bar and a broad flow range of 20-200 L/min, this monoblock directional control valve delivers robust, leak-free performance. Its compact design integrates up to 8 sections, offering incredible flexibility for complex hydraulic systems. Choose from manual, joystick, pneumatic, or electro-hydraulic control to precisely match your machine's needs. Engineered for durability in temperatures from -40°C to 80°C, the DCV100 ensures maximum uptime and efficiency. Stop compromising—upgrade to reliability and request a quote today!
The DCV100 manual directional control valve is built to withstand the most demanding conditions with a rated pressure of 350 bar. This makes it an ideal high-pressure hydraulic valve for heavy-duty construction machinery and drilling equipment, where system failures are not an option. Its robust monoblock construction ensures zero internal leakage and consistent performance under intense pressure shocks, directly addressing the core customer need for ultimate reliability and reduced downtime in critical applications.
With an incredibly wide rated flow range of 20-200 L/min, this monoblock valve offers unparalleled application flexibility. OEMs can standardize on this single model for a variety of machines, from smaller agricultural implements to large industrial equipment, drastically simplifying inventory and system design. This versatility, combined with its compatibility with a wide viscosity range of hydraulic fluids (12-400 mm²/s), makes it a cost-effective and future-proof hydraulic control valve for global machine platforms.
Beyond standard manual control, the DCV100 supports joystick, cable, pneumatic, and electro-hydraulic control valves, providing seamless integration into both simple and sophisticated operating systems. This flexibility is crucial for manufacturers designing next-generation equipment that requires precise control, operator comfort, and readiness for automation, meeting the evolving market demand for smarter, more efficient machinery.
Engineered to operate flawlessly in a vast temperature range from -40°C to 80°C, this valve guarantees performance in the world's most extreme climates. Whether it's a frozen worksite or a scorching desert, the DCV100's design ensures reliable cold starts and stable operation, protecting your machinery from costly downtime. This exceptional resilience addresses the critical customer pain point of needing a component that can endure unpredictable and harsh environmental conditions.
Please confirm below specifications before placing order to ensure proper matching with your hydraulic system:
Hydraulic Pump Rated Flow
This valve is rated 80 L/min. Confirm the actual output flow of your hydraulic gear pump. Do not exceed the nominal flow for long-term continuous operation to avoid excessive pressure loss and overheating.
System Working Pressure
Max continuous working pressure: 31 Mbar. Confirm your system set pressure via main relief valve. Ensure system pressure will not surpass the valve’s pressure rating.
Valve Control Method
Standard: Manual lever control. Optional: Pneumatic actuator for remote cabin operation. Please confirm whether pneumatic control assemblies need to be pre-installed.
Number of Spools
Confirm required spool quantity (1~12 spools available, common: 2/3/4 spools). Each spool controls one hydraulic actuator (cylinder/hydraulic motor).
Spool Center Function
Multiple center functions optional (O-type, Y-type etc.). O-type for cylinder holding/lifting; Y-type for floating application.
Optional Valves Configuration
Confirm if A/B ports need overload & anti-cavitation valves; integrated main relief valve and load check valve are standard.
Mounting Installation Space
Check reserved mounting space on vehicle chassis. Verify overall dimension including handles and optional pneumatic cylinders to avoid installation interference.
Application Working Condition
Confirm equipment type (dump truck, hook lift truck, sanitation vehicle etc.) and working cycle, to match suitable sealing material for harsh environment.
Q: What is the maximum flow and working pressure of this DCV100 multi-way valve? Can it fit heavy-duty dump trucks?
A: Our DCV100 sectional valve supports rated flow 80L/min with maximum continuous working pressure up to 35 Mbar. It is specially designed for heavy load scenarios! Perfectly matched for heavy dump trucks, hook lift trucks and sanitation vehicles. Please make sure your hydraulic pump output flow does not exceed the valve nominal flow for long-term operation.
Q: Can I switch between local manual operation and cabin remote pneumatic control on this valve?
A: Absolutely! This model comes with manual lever as standard. You can choose to install pneumatic actuators on the side to realize remote air control from the cab. One valve supports two control methods, very flexible for vehicle refitting. You just need to confirm whether you need pneumatic components when ordering.
Q: What details should I confirm before placing an order to avoid wrong model delivery?
A: To ensure perfect matching with your hydraulic system, kindly confirm these key points: number of spools, control method (manual / manual + pneumatic), spool center function, port thread type (G or NPT), and whether overload valves are required. If you select pneumatic control, please also check your air supply pressure.
Q: Is this DCV100 valve interchangeable with other well-known brand hydraulic valves? Do you support OEM service?
A: Yes! Our DCV100 valve has high interchangeability with mainstream sectional directional valves on the market, an ideal cost-saving replacement choice. We fully support OEM customization, including laser printing your brand logo, customized handles and packaging. Welcome to discuss your private label requirements.
