1650
FLYBY
| Availability: | |
|---|---|
| Quantity: | |
| Product Type | POWER TAKE OFF PTO |
| Model Number | 1650 |
| Output direction | Same as the engine |
| Speed ratio | 0.77 |
| Output Torque | 650Nm |
| Compatible Models | Compatible for ZF 16-speed or Shanghai Soda series transmissions such as ZF16S1650, ZF16S2530, 12SOB1850, 16SOK2250, etc |
1. Unmatched Versatility with Broad Transmission Compatibility
The Model 1650 solves a major industry challenge with its innovative multi-model PTO for heavy trucks. Its modular design allows it to be easily adapted to fit a wide range of transmission models from different series, significantly simplifying procurement and inventory management. This versatility means fleet operators and body builders can standardize on a single PTO model for various trucks in their fleet. An integrated adaptive torque management system ensures optimal performance across different transmissions without the need for complex recalibrations. This drastically reduces the costs and complexities associated with stocking multiple, model-specific PTOs, offering unparalleled flexibility and cost-efficiency.
2. Torque Amplification for Extreme Heavy-Duty Applications
Engineered for the toughest jobs, the Model 1650 is a true torque-multiplying PTO. Its 0.77 reduction ratio provides a 1.3x torque amplification, generating a class-leading 650Nm of output torque. This immense power is essential for efficiently lifting massive 25m³+ dump bodies and driving large mixer drums under full load. The gearset is crafted from high-strength carburized steel and undergoes nitriding treatment, achieving a surface hardness over HRC 60 to withstand instantaneous shock loads up to 3000Nm. This makes it the ultimate heavy-duty PTO for construction and mining, where failure is not an option and brute force is a daily requirement.
3. Optimized for High Efficiency in Demanding Urban Operations
Beyond raw power, the Model 1650 is designed for operational economy. Its optimized gear design and precision manufacturing achieve a 98.5% power transfer efficiency, reducing energy consumption by 4% compared to standard PTOs. A critical advantage is its ability to deliver rated torque at just 1500 engine RPM. This high-efficiency PTO for dump trucks provides exceptional low-speed performance, making it perfectly suited for urban dump trucks that face constant stop-start cycles. It ensures quick and powerful lift-off from a standstill, improving job cycle times and overall worksite productivity without straining the engine.
4. Engine-Synchronous Output for Simplified System Integration
The Model 1650 features an output rotation that is synchronized with the engine, a key design that streamlines the entire hydraulic system layout. This engine-synchronized PTO design shortens the power transmission path, minimizes energy losses, and reduces the number of components needed. The strategically positioned output flange offers greater flexibility for hydraulic pump mounting. Furthermore, its compatibility with universal joint connections helps compensate for minor installation misalignments, which in turn reduces vibration and noise. This results in a smoother, more reliable, and quieter operation, enhancing overall vehicle refinement and driver comfort.
5. Robust Construction and Intelligent Cooling for Maximum Uptime
Durability and reliability are paramount. The Model 1650 is built to be a robust PTO for quarry trucks, featuring an integrated thermal management system. This system includes an oil temperature sensor and a smart cooling valve that automatically activates forced cooling if oil temperature exceeds 80°C. This ensures stable performance even in scorching ambient temperatures. Coupled with a dual-circuit lubrication system and high-quality bearings, the PTO achieves an extended service life of up to 35,000 hours. This robust design directly tackles the common issue of premature failure, maximizing vehicle uptime and significantly reducing total maintenance costs in harsh environments.
6. Engineered to Conquer the Most Extreme Working Environments
The Model 1650 doesn't just perform; it endures. Certified with an IP6K9K protection rating and equipped with high-temperature sealing technology, it guarantees reliable operation in a staggering temperature range from -40°C to 120°C. Its reinforced dust-proof structure is specifically designed to prevent abrasive particles from entering the system, a common cause of failure in gritty environments. This makes it an ideal PTO for extreme condition trucks operating in open-pit mines and tunnel construction projects. It directly addresses the industry's pain point of frequent PTO failures, offering a solution that stands up to the absolute worst conditions, day in and day out.
